N10276/C276

Introduction

Inconel is a group of austenitic nickel-chromium-based super alloys produced by Special Metals Corporation. Super alloys are referred to as high performance alloys that function well in environments with elevated temperatures.

Super alloy INCONEL C-276 has high molybdenum content which provides the material with localized corrosion resistance like pitting. This alloy is generally known for corrosion resistance in a wide range of aggressive media. The low carbon content in this alloy helps to reduce carbide precipitation while performing welding.

The following section explains in detail about super alloy INCONEL C-276.

Chemical Composition

The chemical composition of INCONEL C-276 is outlined in the following table.

Physical Properties

The physical properties of INCONEL C-276 are tabulated below.

Mechanical Properties

The following table shows mechanical properties of INCONEL C-276.

Thermal Properties

The thermal properties of INCONEL C-276 are tabulated below.

Fabrication and Heat treatment

Welding

Weldability of INCONEL alloy C-276 is rated as good. This material can be used as-welded for most applications.

Hot Working

Hot working of this alloy can be performed 870 and 1230°C (1600 and 2250°F). in case of performing heavy working, it has to be above 1090°C (2000°F).

Annealing

INCONEL alloy C-276 can be annealed at 1150-1175°C (2100-2150°F) and rapidly cooled by water quenching.

Applications

INCONEL C-276 is chiefly used in the following areas:

• Chemical processing
• Pollution control
• Pulp and paper production
• Industrial and municipal waste treatment
• Recovery of sour natural gas.

Products made using INCONEL C-276 are as follows:

• Air pollution control components such as ducts, stack-gas re-heaters, dampers, stack liners, scrubbers, fans and fan housings
• Components required in chemical processing such as reaction vessels, heat exchangers, evaporators, and transfer piping.

Form

Specification

Supply Form

Others

Sheet
