1.4003 stainless steel
Short Description:
Benefits The other benefits of using type 1.4003 stainless steel are listed below: High strength 250 times greater corrosion resistance than mild steel Exceptional impact resistance Can be welded by traditional techniques Can eliminate the need for protective coating Better performance at high temperatures Proven success in several applications across numerous industries Chemical Composition 1.4003 Steel Spec: EN 10088-2:2005 Chemical Element % Present Carbon (C) 0.0 – 0.03 C...
Product Detail
FAQ
Product Tags
Benefits
The other benefits of using type 1.4003 stainless steel are listed below:
- High strength
- 250 times greater corrosion resistance than mild steel
- Exceptional impact resistance
- Can be welded by traditional techniques
- Can eliminate the need for protective coating
- Better performance at high temperatures
- Proven success in several applications across numerous industries
Chemical Composition
| 1.4003 Steel | Spec: EN 10088-2:2005 |
|---|---|
| Chemical Element | % Present |
| Carbon (C) | 0.0 – 0.03 |
| Chromium (Cr) | 10.50 – 12.50 |
| Manganese (Mn) | 0.0 – 1.50 |
| Silicon (Si) | 0.0 – 1.00 |
| Phosphorous (P) | 0.0 – 0.04 |
| Sulphur (S) | 0.0 – 0.02 |
| Nickel (Ni) | 0.30 – 1.00 |
| Nitrogen (N) | 0.0 – 0.03 |
| Iron (Fe) | Balance |
Properties
| Physical Property | Value |
|---|---|
| Density | 7.74 g/cm³ |
| Melting Point | 1430-1510°C |
| Thermal Expansion | 11.1-12.3 x10^-6 /K |
| Modulus of Elasticity | 200 GPa |
| Thermal Conductivity | 30.5 W/m.K |
| Electrical Resistivity | 0.0678 x10^-6 Ω .m |
| Sheet & Plate – Up to 13.5mm Thick | Spec: EN 10088-2:2005 |
|---|---|
| Mechanical Property | Value |
| Proof Stress | 280 Min MPa |
| Tensile Strength | 450-650 MPa |
| Elongation A | 20 Min % |
| Plate – Over 13.5mm to 25mm Thick | Spec: EN 10088-2:2005 |
|---|---|
| Mechanical Property | Value |
| Proof Stress | 250 Min MPa |
| Tensile Strength | 450 – 650 MPa |
| Elongation A | 18 Min % |
